LWB AIR SLIDE BRACKET (CURRENT PRODUCTION STYLE) Includes Bushings MOUNTED HEIGHT LWB LOCKING WEDGE FW BKTLWB6PT* 6-3/4" FW BKTLWB7PT* 7-1/4" FW BKTLWB8PT* 8-1/4" FW BKTLWB9PT 9-1/4" FW BKTLWB10PT 10-1/4" ATB REPAIR KITS & PARTS DESCRIPTION FW KIT-PIN-LLB Pins, Bushings, and Bracket Liners FW BSH-LLB Bushings & Liners (Pair) SLIDE RAILS SLIDE TRAVEL OVERALL LENGTH FW SLRLWB24 24" 45" MIDWESTWHEEL.COM MEMBER KANSAS CITY 5801 E. Front St. Main ....(816) 471-1552 Parts....(800) 821-7402 JOPLIN 2424 Stephens Blvd. Main ....(417) 717-6022 Parts....(866) 318-9111 SPRINGFIELD 812 Lillian Dr. ∙ Strafford, MO Main ....(417) 429-2476 Parts....(800) 785-3705 SIOUX CITY 1819 4th St. Main ....(712) 252-7969 Parts....(800) 943-3534 CEDAR RAPIDS 200 50th Ave. S.W. Main ....(319) 365-4453 Parts....(800) 332-5435 DES MOINES 1436 E. Ovid Ave. Main ....(515) 265-1491 Parts....(800) 888-0248 CLEAR LAKE 840 Hwy. 18 W. Main ....(641) 357-7101 Parts....(800) 397-5630 DAVENPORT 8502 Northwest Blvd. Main ....(563) 322-2671 Parts....(800) 553-1886 OMAHA 9770 S 142nd Street, Suite 1 Main ....(531) 239-3050 Parts....(800) 322-8757 NEBRASKA IOWA MISSOURI January 7, 2025 (19Fifth Wheel 2025) • Cast Steel • Pull force required to open the lock: 85 lbs. • Cast Steel housing with a grease-free coupling surface • Pull force required to open the lock: 85 lbs. • Patented self-adjusting No-Slack® locking mechanism • Positive secondary lock that can only be released by pulling the handle • Fabricated steel construction • Pull force required to open the lock: 65 lbs. FW SLTPL7000 FW SLTPL7000CC FW SLTPL6000 FW SLTPLUNT FIFTH WHEEL REPAIR KITS 6000/7000/7000CC H5092/X5092 3000 ULTRA NT (UNT) Major Rebuild Kit FW KIT-RX-67NTL / FW KIT-RX-67NTR FW KIT-RX-5092L FW KIT-RX-3000L FW KIT-RX-67NTL Minor Rebuild Kit FW KIT-RPR-6000(L)(R) FW KIT-RPR-5092(L)(R) FW KIT-RPR-6000(L)(R) Wedge-Stop Rod Kit FW KIT-ROD-1108 FW KIT-ROD-1108 FW KIT-ROD-1108 Bracket Pin Kit (1 pc bushing) FW KIT-PIN-191 FW KIT-PIN-191 FW KIT-PIN-3000 FW KIT-PIN-UNT Bracket Pin Kit (2 pc bushing) FW KIT-PIN-LLB Secondary Lock Kit FW KIT-LAT-6000L / FW KIT-RX-67NTR FW KIT-LAT-6000L / FW KIT-RX-67NTR Spring Kit Contains (1) SPR-338, (1) SPR-374 & (1) CD-SPR-236 FW KIT-SPRING FW KIT-SPRING Bumper Kit (Bumper Spring Only: FW SPR-128) FW KIT-BPR-6000L / FW KIT-RX-67NTR FW KIT-BPR-6000L / FW KIT-RX-67NTR Timer Kit FW KIT-TMR-6000L / FW KIT-RX-67NTR FW KIT-RX-5092L FW KIT-TMR-6000L / FW KIT-RX-67NTR Operating Handle Kit FW KIT-OPR-6000 FW KIT-RX-3000L FW KIT-OPR-6000 Pull Handle Kit FW KIT-PUL-6000(L)(R) FW KIT-RX-5092L FW KIT-RX-3000L Clean Connect Plates FW CCR-PLATES-(L)(R) (7000CC only) Air Cylinder 12-1/4” Hole Centers, 7/8” Diameter Holes FW CYL-COMP FW CYL-COMP FW CYL-COMP FW CYL-COMP AWB AIR SLIDE BRACKET (OLD STYLE) Includes Bushings MOUNTED HEIGHT AWB LOCKING WEDGE FW BKTAWB6PT* 6-3/4" FW BKTAWB7PT 7-3/4" FW BKTAWB8PT 8-3/4" FW BKTAWB9PT 9-3/4" FW BKTAWB10PT 10-3/4" ATB REPAIR KITS & PARTS DESCRIPTION FW KIT-PIN-191 Pins and Bushings FW BSH-150 Bushings (Pair) SLIDE RAILS SLIDE TRAVEL OVERALL LENGTH FW SLR-24-B 24" 54" Capacity: 55,000 lbs. Maximum Vertical Load 150,000 lbs. Maximum Drawbar Pull Left Hand Release Weight: 245 lbs Capacity: 55,000 lbs. Maximum Vertical Load 150,000 lbs. Maximum Drawbar Pull Left Hand Release Weight: 248 lbs Capacity: 50,000 lbs. Maximum Vertical Load 150,000 lbs. Maximum Drawbar Pull Left Hand Release Weight: 220 lbs FONTAINE TOP PLATES 7000 Series Top Plate 7000CC Series Clean Connect Top Plate 6000 Series Top Plate Ultra NT No-Slack® Top Plate (discontinued) *All top plates come with pins. Bushings sold separately. 7000 Series FW SL7LWB675024 24" Slide Length; 6 3/4" fifth wheel height FW SL7LWB725024 24" Slide Length; 7 1/4" fifth wheel height FW SL7LWB825024 24" Slide Length; 8 1/4" fifth wheel height FW SL7LWB925024 24” Slide Length; 9 1/4" fifth wheel height 6000 Series FW SL6LWB675024 24" Slide Length; 6 3/4" fifth wheel height FW SL6LWB725024 24" Slide Length; 7 1/4" fifth wheel height FW SL6PML6250 Stationary; 6 1/4" fifth wheel height FW SL6PML7250 Stationary; 7 1/4" fifth wheel height • Safety trigger eliminates the possibility of false coupling to prevent dangerous high-hitching FONTAINE COMPLETE ASSEMBLIES See below for 6000 Series & 7000 Series Features SLTPLUNT – Top Plate Replacements (And all SLNTLWO assemblies, brackets and rails) have been discontinued Replacement Options: Complete assemblies through conversion program: www.fifthwheel.com/convert (You will need existing ride height and slide travel) Complete assembly program is competitively priced and comes with a 5 year warranty on the full system. Complete Assembly Bolt Kit for Stationary, 12" and 24" Slide Rails NEW! Mounting Angles - Provides an easy way to securely attach 5th Wheel to a truck chassis
